Byonk

Bring Your Own Ink - Self-hosted content server for TRMNL e-ink devices

Features

• Lua Scripting - Fetch data from any API, scrape websites, process JSON - all with simple Lua scripts.
• SVG Templates - Design pixel-perfect screens using SVG with Tera templating (Jinja2-style syntax).
• Variable Fonts - Full support for variable font weights via CSS font-variation-settings.
• Smart Refresh - Scripts control when devices refresh - optimize for fresh data and battery life.
• 4-Level Grayscale - Blue-noise dithering optimized for e-paper’s 4 gray levels.
• Device Mapping - Assign different screens to different devices via simple YAML configuration.

Quick Start

# Run with Docker
docker run -d -p 3000:3000 ghcr.io/oetiker/byonk:latest

Or download a pre-built binary for your platform.

Point your TRMNL device to http://your-server:3000 and it will start displaying content.

How It Works

flowchart LR
    A[Lua Script] --> B[SVG Template] --> C[Dithering] --> D[TRMNL PNG]

1. Lua scripts fetch data from APIs or scrape websites
2. SVG templates render the data into beautiful layouts
3. Renderer converts SVG to dithered PNG optimized for e-ink
4. Device displays the content and sleeps until next refresh

Example: Transit Departures

Lua Script fetches real-time data:

local response = http_get("https://transport.opendata.ch/v1/stationboard?station=Olten")
local data = json_decode(response)

return {
  data = { departures = data.stationboard },
  refresh_rate = 60
}

SVG Template renders the display:

<svg viewBox="0 0 800 480">
  {% for dep in departures %}
  <text y="{{ 100 + loop.index0 * 40 }}">
    {{ dep.category }}{{ dep.number }} → {{ dep.to }}
  </text>
  {% endfor %}
</svg>

Result on e-ink display:

Next Steps

• Installation Guide - Set up Byonk on your server
• Architecture - Understand how Byonk works
• Create Your First Screen - Build a custom display
• API Reference - HTTP and Lua API documentation

Installation

Byonk can be installed via Docker container or pre-built binaries. All screens, fonts, and configuration are embedded in the binary, so it works out of the box with zero configuration.

Quick Start

# Just run it - embedded assets work immediately
docker run -p 3000:3000 ghcr.io/oetiker/byonk:latest

That’s it! The server is running with embedded default screens.

Docker (Recommended)

Zero-Config Mode

The simplest way to run Byonk:

docker run -d \
  --name byonk \
  -p 3000:3000 \
  ghcr.io/oetiker/byonk:latest

This uses embedded screens, fonts, and config - no volumes needed.

Customization Mode

To customize screens and config, mount volumes and set environment variables:

docker run -d \
  --name byonk \
  -p 3000:3000 \
  -e SCREENS_DIR=/data/screens \
  -e FONTS_DIR=/data/fonts \
  -e CONFIG_FILE=/data/config.yaml \
  -v ./data:/data \
  ghcr.io/oetiker/byonk:latest

On first run with empty directories, Byonk automatically seeds them with embedded defaults.

Available tags:

• latest - Latest stable release
• 0 - Latest v0.x release
• 0.4 - Latest v0.4.x release
• 0.4.0 - Specific version

Docker Compose

Zero-config:

services:
  byonk:
    image: ghcr.io/oetiker/byonk:latest
    ports:
      - "3000:3000"
    restart: unless-stopped

With customization:

services:
  byonk:
    image: ghcr.io/oetiker/byonk:latest
    ports:
      - "3000:3000"
    environment:
      - SCREENS_DIR=/data/screens
      - FONTS_DIR=/data/fonts
      - CONFIG_FILE=/data/config.yaml
    volumes:
      - ./data:/data  # Empty on first run = auto-seeded
    restart: unless-stopped

Pre-built Binaries

Download the latest release from GitHub Releases.

Available platforms:

• x86_64-unknown-linux-gnu - Linux (Intel/AMD 64-bit)
• aarch64-unknown-linux-gnu - Linux (ARM 64-bit, e.g., Raspberry Pi 4)
• x86_64-apple-darwin - macOS (Intel)
• aarch64-apple-darwin - macOS (Apple Silicon)
• x86_64-pc-windows-msvc - Windows

Extract and run:

tar -xzf byonk-*.tar.gz
./byonk

By default, Byonk listens on 0.0.0.0:3000 and uses embedded assets.

Extracting Embedded Assets

To customize the embedded screens and config:

# See what's embedded
./byonk init --list

# Extract everything for editing
./byonk init --all

# Extract specific categories
./byonk init --screens
./byonk init --config

Directory Structure (When Customizing)

When using external files (via env vars), Byonk expects:

data/
├── config.yaml          # Device and screen configuration
├── screens/             # Lua scripts and SVG templates
│   ├── default.lua
│   ├── default.svg
│   └── ...
└── fonts/               # Custom fonts (optional)
    └── Outfit-Variable.ttf

Environment Variables

When path variables are not set, Byonk uses embedded assets (no filesystem access).

Running as a Service (systemd)

Create /etc/systemd/system/byonk.service:

[Unit]
Description=Byonk Content Server
After=network.target

[Service]
Type=simple
User=byonk
WorkingDirectory=/opt/byonk
ExecStart=/opt/byonk/byonk serve
Environment="BIND_ADDR=0.0.0.0:3000"
Restart=always
RestartSec=5

[Install]
WantedBy=multi-user.target

Enable and start:

sudo systemctl enable byonk
sudo systemctl start byonk

CLI Commands

Status (Default)

Running byonk without arguments shows current configuration:

./byonk

Server

Start the HTTP server:

./byonk serve

Render

Render a screen directly to PNG (useful for testing):

./byonk render --mac "00:00:00:00:00:00" --output test.png

Options:

Example with all device info:

./byonk render -m "AC:15:18:D4:7B:E2" -o test.png \
  --battery=4.12 --rssi=-67 --firmware="1.2.3"

Note: Use = syntax for negative numbers (e.g., --rssi=-67).

Init

Extract embedded assets for customization:

./byonk init --all        # Extract everything
./byonk init --screens    # Extract screens only
./byonk init --list       # List embedded assets

Verifying Installation

1. Open http://your-server:3000/health - should return “OK”
2. Open http://your-server:3000/swagger-ui - shows API documentation
3. Point a TRMNL device to your server to test

Configuring Your TRMNL Device

To use Byonk with your TRMNL device, configure the device to point to your server instead of the default TRMNL cloud service.

Note: Refer to TRMNL documentation for instructions on configuring a custom server URL.

Next Steps

• Configure your screens and devices
• Create your first screen

Configuration

Byonk embeds all screens, fonts, and configuration in the binary itself. This means you can run Byonk with zero configuration - it works out of the box.

For customization, Byonk uses a YAML configuration file to define screens and map devices to them.

Configuration Structure

# Screen definitions
screens:
  transit:
    script: transit.lua        # Lua script in screens/
    template: transit.svg      # SVG template in screens/
    default_refresh: 60        # Fallback refresh rate (seconds)

  weather:
    script: weather.lua
    template: weather.svg
    default_refresh: 900

# Device-to-screen mapping
devices:
  "94:A9:90:8C:6D:18":         # Device MAC address
    screen: transit             # Which screen to display
    params:                     # Parameters passed to Lua script
      station: "Olten, Bahnhof"
      limit: 8

  "AA:BB:CC:DD:EE:FF":
    screen: weather
    params:
      city: "Zurich"

# Default screen for unmapped devices
default_screen: default

Screens Section

Each screen definition has three properties:

The default_refresh is used when the Lua script returns refresh_rate = 0 or omits it entirely.

Devices Section

Each device entry maps a MAC address to a screen:

MAC Address Format

• Use uppercase letters with colons: "94:A9:90:8C:6D:18"
• The MAC address must be quoted (it’s a YAML string)

Parameters

The params section can contain any YAML values:

params:
  # Strings
  station: "Olten, Bahnhof"

  # Numbers
  limit: 8
  temperature_offset: -2.5

  # Booleans
  show_delays: true

  # Lists
  rooms:
    - "Rosa"
    - "Flora"

These are available in Lua as the global params table:

local station = params.station or "Default Station"
local limit = params.limit or 10

Default Screen

The default_screen specifies which screen to show for devices not listed in the devices section:

default_screen: default

If omitted, unknown devices receive an error response.

Hot Reloading

Byonk loads Lua scripts and SVG templates fresh on every request. You can edit these files without restarting the server.

However, config.yaml is only loaded at startup. Changes to device mappings or screen definitions require a server restart.

Example: Complete Configuration

# Byonk Configuration

screens:
  # Default screen - shows time and a message
  default:
    script: default.lua
    template: default.svg
    default_refresh: 300

  # Public transport departures
  transit:
    script: transit.lua
    template: transit.svg
    default_refresh: 60

  # Room booking display
  floerli:
    script: floerli.lua
    template: floerli.svg
    default_refresh: 900

devices:
  # Kitchen display - bus departures
  "94:A9:90:8C:6D:18":
    screen: transit
    params:
      station: "Olten, Südwest"
      limit: 8

  # Office display - room booking
  "AA:BB:CC:DD:EE:FF":
    screen: floerli
    params:
      room: "Rosa"

  # Lobby display - different bus stop
  "BB:CC:DD:EE:FF:00":
    screen: transit
    params:
      station: "Olten, Bahnhof"
      limit: 6

default_screen: default

Embedded Assets

Byonk includes default screens, fonts, and configuration embedded in the binary. This enables zero-config operation:

# Just run it - embedded defaults work immediately
byonk serve

To see what’s embedded:

byonk init --list

Customization Modes

1. Zero-config (embedded only):

byonk serve
# Uses embedded screens, fonts, and config

2. Full customization (env vars + volume mounts):

export SCREENS_DIR=/data/screens
export FONTS_DIR=/data/fonts
export CONFIG_FILE=/data/config.yaml
byonk serve
# Empty paths are auto-seeded with embedded defaults
# Then uses external files (with embedded fallback)

3. Extract for editing:

byonk init --all
# Extracts embedded assets to ./screens/, ./fonts/, ./config.yaml

Init Command

The byonk init command extracts embedded assets to the filesystem:

# List embedded assets
byonk init --list

# Extract everything
byonk init --all

# Extract specific categories
byonk init --screens
byonk init --fonts
byonk init --config

# Force overwrite existing files
byonk init --all --force

# Extract to custom locations (via env vars)
SCREENS_DIR=/my/screens byonk init --screens

Auto-Seeding

When you set an environment variable pointing to an empty or missing directory, Byonk automatically seeds it with embedded assets on startup:

# This creates /data/screens with embedded screens on first run
SCREENS_DIR=/data/screens byonk serve

Merge Behavior

External files take precedence over embedded assets:

1. If external file exists → use it
2. If external file is missing → fall back to embedded

This lets you customize individual screens while keeping embedded defaults for others.

Environment Variables

When a path env var is not set, embedded assets are used exclusively (no filesystem access).

File Locations

Docker Usage

For Docker, mount volumes and set env vars to enable customization:

services:
  byonk:
    image: ghcr.io/oetiker/byonk
    ports:
      - "3000:3000"
    environment:
      - SCREENS_DIR=/data/screens
      - FONTS_DIR=/data/fonts
      - CONFIG_FILE=/data/config.yaml
    volumes:
      - ./data:/data  # Empty on first run = auto-seeded

Or run without volumes for pure embedded mode:

services:
  byonk:
    image: ghcr.io/oetiker/byonk
    ports:
      - "3000:3000"
    # No volumes = uses embedded assets only

Next Steps

• Understand the architecture
• Create your first screen

Architecture Overview

Byonk is designed as a content server that bridges dynamic data sources with e-ink displays. This page explains how the system is structured and how requests flow through it.

System Overview

flowchart LR
    Display[TRMNL Display]

    subgraph Server[Byonk Server]
        Router[HTTP Router]
        Registry[(Device Registry)]
        Signer[URL Signer]
        Lua[Lua Runtime]
        Template[Template Service]
        Renderer[SVG Renderer]
    end

    Display --> Router
    Router --> Registry
    Router --> Signer
    Router --> Lua
    Lua --> Template
    Template --> Renderer

Core Components

HTTP Router

The entry point for all device requests. Built with Axum, it handles:

• Device registration (/api/setup)
• Content requests (/api/display, /api/image/:id)
• Logging (/api/log)
• API documentation (/swagger-ui)

Device Registry

Stores device information in memory:

• MAC address to API key mapping
• Device metadata (firmware version, model, battery level)
• Last seen timestamps

Note: The current implementation uses an in-memory store. Device registrations are lost on restart. The architecture supports adding database persistence in the future.

URL Signer

Provides security for image URLs using HMAC-SHA256:

• Signs image URLs with expiration timestamps
• Validates signatures on image requests
• Prevents unauthorized access to device content

Content Pipeline

The heart of Byonk - orchestrates content generation:

1. Looks up screen configuration for the device
2. Executes Lua script with device parameters
3. Renders SVG template with script data
4. Converts SVG to PNG with dithering

Lua Runtime

Executes Lua scripts in a sandboxed environment:

• HTTP client for fetching external data
• JSON/HTML parsing utilities
• Time functions
• Logging

Template Service

Renders SVG templates using Tera:

• Jinja2-style syntax
• Custom filters (truncate, format_time)
• Fresh loading on each request (hot reload)

SVG Renderer

Converts SVG to PNG optimized for e-ink:

• Uses resvg for rendering
• Loads custom fonts from fonts/ directory
• Blue-noise dithering to 4 gray levels
• Outputs 2-bit indexed PNG

Request Flow

The device-server interaction happens in three phases:

Phase 1: Device Registration

sequenceDiagram
    participant Device as E-ink Display
    participant Router as HTTP Router
    participant Registry as Device Registry

    Device->>+Router: GET /api/setup
    Router->>Registry: lookup/create device
    Registry-->>Router: api_key
    Router-->>-Device: {api_key, friendly_id}
    Note right of Device: Store api_key

Phase 2: Content Generation

sequenceDiagram
    participant Device
    participant Router
    participant Lua
    participant API as External API
    participant Template
    participant Cache

    Device->>+Router: GET /api/display
    Router->>+Lua: execute script
    Lua->>+API: http_get(url)
    API-->>-Lua: JSON data
    Lua-->>-Router: {data, refresh_rate}
    Router->>+Template: render SVG with data
    Template-->>-Router: SVG document
    Router->>Cache: store SVG + hash
    Router-->>-Device: {image_url, filename, refresh_rate}
    Note right of Device: filename is content hash

Phase 3: Image Rendering

sequenceDiagram
    participant Device
    participant Router
    participant Cache
    participant Renderer

    Device->>+Router: GET /api/image/:id
    Router->>Cache: get cached SVG
    Cache-->>Router: SVG document
    Router->>+Renderer: convert to PNG
    Renderer-->>-Router: dithered PNG
    Router-->>-Device: PNG image
    Note right of Device: Display and sleep

Request Details

Phase 2 (content generation):

1. Load and execute Lua script with params and device context
2. Script fetches external data via http_get()
3. Render SVG template with script data
4. Cache rendered SVG with content hash
5. Sign image URL and return to device with filename set to content hash

The filename field contains a hash of the rendered SVG content. This allows TRMNL devices to detect when content has actually changed, even if the same screen is configured.

Phase 3 (image rendering):

1. Verify URL signature
2. Retrieve cached SVG
3. Convert SVG to PNG with blue-noise dithering
4. Return PNG to device

Technology Stack

Design Principles

Fresh Loading

Lua scripts and SVG templates are loaded from disk on every request. This enables:

• Live editing during development
• No restart needed for content changes
• Simple deployment (just copy files)

Blocking Isolation

CPU-intensive operations run in a blocking task pool:

• Lua HTTP requests
• SVG rendering
• Image encoding

This prevents blocking the async event loop.

Graceful Degradation

If content generation fails, devices receive an error screen rather than nothing. The error message helps debugging while keeping the device functional.

Security Model

Signed URLs

Image URLs are signed with HMAC-SHA256:

• 1-hour expiration
• Prevents URL enumeration
• Protects against unauthorized access

No Authentication Required

The /api/setup endpoint is open - any device can register. This matches TRMNL’s design where devices self-register.

Script Sandboxing

Lua scripts run in a controlled environment:

• Only exposed functions are available
• No filesystem access
• No arbitrary code execution

Content Pipeline

The content pipeline is how Byonk transforms data into images for e-ink displays. This page explains each stage in detail.

Pipeline Overview

flowchart TD
    A[Lua Script] -->|JSON data| B[SVG Template]
    B -->|SVG document| C[Cache]
    C -->|cached SVG| D[Renderer]
    D -->|dithered pixels| E[E-ink PNG]

Content Change Detection

TRMNL devices use the filename field in the /api/display response to detect content changes. Byonk computes a SHA-256 hash of the rendered SVG content and returns it as the filename. This means:

• Same content = same filename: If your Lua script returns identical data and the template produces the same SVG, the device knows nothing changed
• Changed content = new filename: Any change in the rendered SVG (data, template, or device context) produces a new hash

This is why template rendering happens during /api/display rather than /api/image - the hash must be known before the device decides whether to fetch the image.

Stage 1: Lua Script Execution

Lua scripts fetch and process data from external sources.

Input

The script receives a global params table from config.yaml:

# config.yaml
devices:
  "94:A9:90:8C:6D:18":
    screen: transit
    params:
      station: "Olten, Bahnhof"
      limit: 8

-- In your script
local station = params.station  -- "Olten, Bahnhof"
local limit = params.limit      -- 8

Processing

Scripts can:

• Fetch HTTP data: APIs, web pages, JSON endpoints
• Parse content: JSON decoding, HTML scraping
• Transform data: Filter, sort, calculate

local response = http_get("https://api.example.com/data")
local data = json_decode(response)

local filtered = {}
for _, item in ipairs(data.items) do
  if item.active then
    table.insert(filtered, item)
  end
end

Output

Scripts must return a table with two fields:

return {
  data = {
    -- Any structure - passed to template
    title = "My Screen",
    items = filtered,
    updated_at = time_format(time_now(), "%H:%M")
  },
  refresh_rate = 300  -- Seconds until next update
}

Refresh Rate

The refresh_rate controls when the device fetches new content:

• Low values (30-60s): Real-time data (transit, stocks)
• Medium values (300-900s): Regular updates (weather, calendar)
• High values (3600+s): Static content

Tip: Calculate refresh rates dynamically. For transit, refresh after the next departure:

local seconds_until_departure = departure_time - time_now()
return {
  data = departures,
  refresh_rate = seconds_until_departure + 30
}

Stage 2: Template Rendering

SVG templates use Tera syntax (similar to Jinja2).

Input

The template receives a structured context with three namespaces:

Template Namespaces

Device Context Variables

These are automatically available under device.* (when reported by the device):

<!-- Show battery voltage in header -->
<text x="780" y="30" text-anchor="end">
  {% if device.battery_voltage %}{{ device.battery_voltage | round(precision=2) }}V{% endif %}
</text>

Note: Device info is also available in Lua scripts via the device global table.

Syntax

Variables:

<text>{{ data.title }}</text>
<text>{{ data.user.name }}</text>
<text>{{ device.battery_voltage }}V</text>
<text>{{ params.station }}</text>

Loops:

{% for item in data.items %}
<text y="{{ 100 + loop.index0 * 30 }}">{{ item.name }}</text>
{% endfor %}

Conditionals:

{% if data.error %}
<text fill="red">{{ data.error }}</text>
{% else %}
<text>All good!</text>
{% endif %}

Built-in Filters

Output

A complete SVG document ready for rendering.

Stage 3: SVG to PNG Conversion

The renderer converts SVG to a PNG optimized for e-ink displays.

Font Handling

1. Custom fonts from fonts/ directory (loaded first)
2. System fonts as fallback
3. Variable fonts supported via CSS font-variation-settings

<style>
  .title {
    font-family: Outfit;
    font-variation-settings: "wght" 700;
  }
</style>

Scaling

SVGs are scaled to fit the display while maintaining aspect ratio:

• TRMNL OG: 800 × 480 pixels
• TRMNL X: 1872 × 1404 pixels

The image is centered if the aspect ratio doesn’t match exactly.

Grayscale Conversion

Colors are converted to grayscale using the ITU-R BT.709 formula:

Y = 0.2126 × R + 0.7152 × G + 0.0722 × B

This matches human perception of brightness.

Stage 4: Blue-Noise Dithering

E-ink displays only support 4 gray levels. Dithering creates the illusion of more shades.

Byonk uses blue-noise-modulated error diffusion dithering, an improved algorithm that reduces visible “worm” artifacts while preserving sharp edges for UI content.

How It Works

The algorithm improves upon standard Floyd-Steinberg in three ways:

1. Serpentine scanning: Alternates row direction (left-to-right, then right-to-left) to reduce directional artifacts
2. Blue noise modulation: Adds subtle randomness to the quantization threshold, breaking up repetitive patterns
3. Energy-preserving error: Error is computed from the un-noised value to maintain correct brightness

For each pixel:
  1. Get blue noise value for this position (64×64 tiled pattern)
  2. Add noise offset to pixel value (modulates threshold)
  3. Quantize to nearest level: [0, 85, 170, 255]
  4. Calculate error from ORIGINAL value (not noised)
  5. Distribute error to neighbors (direction depends on row):

     Left-to-right:      Right-to-left:
         X   7/16        7/16   X
     3/16 5/16 1/16      1/16 5/16 3/16

Why Blue Noise?

Standard Floyd-Steinberg can produce visible “worm” patterns in mid-gray areas. Blue noise has a frequency distribution that appears random to the eye but lacks low-frequency components, producing more pleasing results on e-ink displays.

Gray Levels

Output Format

The final PNG is:

• 2-bit indexed color (4 colors in palette)
• 4 pixels per byte for compact size
• Size validated against device limits (90KB for OG, 750KB for X)

Error Handling

If any stage fails, Byonk generates an error screen:

<svg>
  <rect fill="white" stroke="red" stroke-width="5"/>
  <text>Error: Failed to fetch data</text>
  <text>Will retry in 60 seconds</text>
</svg>

This ensures:

• Device always receives valid content
• Error is visible for debugging
• Automatic retry on next refresh

Performance Considerations

What’s Fast

• Lua script execution (milliseconds)
• Template rendering (milliseconds)
• Simple SVG rendering (10-50ms)

What’s Slower

• HTTP requests (network dependent)
• Complex SVG with many elements (100-500ms)
• Large images or gradients

Optimization Tips

1. Minimize HTTP calls - Cache data in script if possible
2. Simplify SVG - Fewer elements = faster rendering
3. Avoid gradients - They’re converted to dithered patterns anyway
4. Use appropriate refresh rates - Don’t refresh more often than needed

Device Mapping

Byonk allows you to show different content on different TRMNL devices. This page explains how devices are identified, registered, and mapped to screens.

How Devices Are Identified

Each TRMNL device has a unique MAC address that identifies it. This address is sent in the ID header with every request:

ID: 94:A9:90:8C:6D:18

Byonk uses this MAC address to:

1. Register new devices
2. Look up existing device configuration
3. Map devices to screens

Device Registration Flow

sequenceDiagram
    participant Device
    participant Byonk

    Device->>Byonk: GET /api/setup<br/>Headers: ID, FW-Version, Model
    Byonk-->>Device: {api_key, friendly_id}
    Note right of Device: Store api_key

    Device->>Byonk: GET /api/display<br/>Headers: Access-Token, ID
    Byonk-->>Device: {image_url, refresh_rate}

Setup Response

{
  "status": 200,
  "api_key": "a1b2c3d4e5f6...",
  "friendly_id": "abc123def456"
}

• api_key: Authentication token for subsequent requests
• friendly_id: Human-readable identifier (12 hex characters)

Configuration-Based Mapping

Devices are mapped to screens in config.yaml:

devices:
  "94:A9:90:8C:6D:18":
    screen: transit
    params:
      station: "Olten, Bahnhof"

  "AA:BB:CC:DD:EE:FF":
    screen: weather
    params:
      city: "Zurich"

default_screen: default

Lookup Order

When a device requests content:

1. Exact MAC match - Check if MAC is in devices section
2. Default screen - Use default_screen if no match
3. Error - Return error if no default configured

MAC Address Format

MAC addresses in config must be:

• Uppercase: "94:A9:90:8C:6D:18" not "94:a9:90:8c:6d:18"
• Colon-separated: "94:A9:90:8C:6D:18" not "94-A9-90-8C-6D-18"
• Quoted: YAML requires quotes for strings with colons

Device Parameters

Each device can have custom parameters passed to its screen’s Lua script:

devices:
  "94:A9:90:8C:6D:18":
    screen: transit
    params:
      station: "Olten, Südwest"
      limit: 8
      show_delays: true

In the Lua script:

local station = params.station      -- "Olten, Südwest"
local limit = params.limit          -- 8
local show_delays = params.show_delays  -- true

Parameter Types

You can use any YAML type:

Same Screen, Different Parameters

Multiple devices can use the same screen with different parameters:

devices:
  # Kitchen - shows nearby bus stop
  "94:A9:90:8C:6D:18":
    screen: transit
    params:
      station: "Olten, Südwest"

  # Office - shows train station
  "AA:BB:CC:DD:EE:FF":
    screen: transit
    params:
      station: "Olten, Bahnhof"
      limit: 10

  # Lobby - shows airport
  "BB:CC:DD:EE:FF:00":
    screen: transit
    params:
      station: "Zürich Flughafen"
      limit: 6

Finding Your Device’s MAC Address

The MAC address is shown:

1. In Byonk logs when the device connects:

   INFO Device registered device_id="94:A9:90:8C:6D:18"


2. On the device during setup (check TRMNL documentation)

3. In your router’s connected devices list

Default Screen

The default_screen provides a fallback for:

• Devices not yet configured
• New devices during testing
• Backup if config is incorrect

default_screen: default

If no default_screen is set and a device isn’t in the config, it receives an error response.

Auto-Registration

Byonk automatically registers new devices on their first /api/setup call:

1. Generates a random API key
2. Generates a friendly ID
3. Stores device in registry

No pre-configuration is needed - just add the device to config.yaml to assign a custom screen.

Multiple Screens per Device?

Currently, each device shows one screen. However, you can create a “dashboard” screen that combines multiple data sources:

-- dashboard.lua
local weather = fetch_weather()
local transit = fetch_transit()
local calendar = fetch_calendar()

return {
  data = {
    weather = weather,
    transit = transit,
    calendar = calendar
  },
  refresh_rate = 300
}

Device Metadata

Byonk tracks additional device information from request headers:

This metadata is stored in the device registry and can be used for:

• Debugging connectivity issues
• Monitoring battery levels
• Adapting content to device model

Persistence

Warning: The current implementation stores device registrations in memory. Registrations are lost on server restart.

Devices will automatically re-register on their next request, but any collected metadata is lost.

Future versions may add database persistence for device data.

Tutorial

This tutorial series will teach you how to create custom screens for your TRMNL device using Byonk. You’ll learn:

1. Your First Screen - Create a simple “Hello World” screen
2. Lua Scripting - Fetch data from APIs and process it
3. SVG Templates - Design beautiful layouts
4. Advanced Topics - HTML scraping, dynamic refresh, error handling

Prerequisites

Before starting, make sure you have:

• Byonk installed and running
• A text editor for writing Lua and SVG files
• Basic familiarity with programming concepts

Example Screens

Byonk comes with several example screens you can learn from:

Default Screen

A simple clock display showing time and date.

screens/default.lua   - Script
screens/default.svg   - Template

Transit Departures

Real-time public transport departures from Swiss OpenData.

screens/transit.lua   - Fetches from transport.opendata.ch API
screens/transit.svg   - Displays departure list with colors

Room Booking (Floerli)

Scrapes a web page to show room availability.

screens/floerli.lua   - HTML scraping example
screens/floerli.svg   - Shows current/upcoming bookings

Gray Level Test

Demonstrates the 4 gray levels available on e-ink.

screens/graytest.lua  - Minimal script
screens/graytest.svg  - Four gray rectangles

Quick Reference

File Locations

Workflow

1. Create a Lua script and SVG template in screens/
2. Define a screen in config.yaml
3. Assign the screen to a device
4. Test by refreshing your device or checking /swagger-ui

Tip: Lua scripts and SVG templates are loaded fresh on every request. Just save your changes and refresh!

Ready to Start?

Head to Your First Screen to create your first custom display!

Your First Screen

Let’s create a simple screen that displays a greeting and the current time. This will introduce you to the basic workflow of creating Byonk screens.

Step 1: Create the Lua Script

Create a new file screens/hello.lua:

-- Hello World screen
-- Displays a greeting with the current time

local now = time_now()

return {
  data = {
    greeting = "Hello, World!",
    time = time_format(now, "%H:%M:%S"),
    date = time_format(now, "%A, %B %d, %Y")
  },
  refresh_rate = 60  -- Refresh every minute
}

What this does:

• time_now() gets the current Unix timestamp
• time_format() formats it into readable strings
• The returned data table is passed to the template
• refresh_rate tells the device to check back in 60 seconds

Step 2: Create the SVG Template

Create a new file screens/hello.svg:

<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 800 480" width="800" height="480">
  <style>
    .greeting {
      font-family: sans-serif;
      font-size: 48px;
      font-weight: bold;
      fill: black;
    }
    .time {
      font-family: sans-serif;
      font-size: 72px;
      font-weight: bold;
      fill: black;
    }
    .date {
      font-family: sans-serif;
      font-size: 24px;
      fill: #555;
    }
  </style>

  <!-- White background -->
  <rect width="800" height="480" fill="white"/>

  <!-- Greeting -->
  <text class="greeting" x="400" y="120" text-anchor="middle">
    {{ data.greeting }}
  </text>

  <!-- Large time display -->
  <text class="time" x="400" y="260" text-anchor="middle">
    {{ data.time }}
  </text>

  <!-- Date below -->
  <text class="date" x="400" y="320" text-anchor="middle">
    {{ data.date }}
  </text>

  <!-- Footer -->
  <text x="400" y="450" text-anchor="middle" font-family="sans-serif" font-size="14" fill="#999">
    My first Byonk screen!
  </text>
</svg>

Template features used:

• {{ data.variable }} - Inserts values from the Lua script’s data table
• CSS styling for fonts and colors
• text-anchor="middle" for centered text

Step 3: Add the Screen to Configuration

Edit config.yaml to add your new screen:

screens:
  # ... existing screens ...

  hello:
    script: hello.lua
    template: hello.svg
    default_refresh: 60

Step 4: Assign to a Device

Still in config.yaml, assign the screen to your device:

devices:
  "YOUR:MAC:AD:DR:ES:S0":
    screen: hello
    params: {}

Replace YOUR:MAC:AD:DR:ES:S0 with your device’s actual MAC address.

Tip: Check the Byonk server logs when your device connects - the MAC address is printed there.

Step 5: Test It

1. Restart Byonk (config.yaml changes require restart)

2. Check the API at http://localhost:3000/swagger-ui:

   • Use the /api/display endpoint with your device’s MAC
   • You’ll get a signed image URL
   • Open that URL to see your screen!

3. Or wait for your device to refresh automatically

Understanding the Result

Your screen should look like this:

Adding Parameters

Let’s make the greeting customizable. Update your files:

screens/hello.lua:

local now = time_now()

-- Get name from params, default to "World"
local name = params.name or "World"

return {
  data = {
    greeting = "Hello, " .. name .. "!",
    time = time_format(now, "%H:%M:%S"),
    date = time_format(now, "%A, %B %d, %Y")
  },
  refresh_rate = 60
}

config.yaml:

devices:
  "YOUR:MAC:AD:DR:ES:S0":
    screen: hello
    params:
      name: "Alice"

Now your screen will say “Hello, Alice!” instead of “Hello, World!”.

Troubleshooting

Screen shows error

Check the Byonk logs for script errors:

./target/release/byonk
# Look for ERROR or WARN lines

Template variables not replaced

Make sure your Lua script returns a data table with the expected keys:

return {
  data = {
    greeting = "Hello"  -- Must match {{ greeting }} in template
  },
  refresh_rate = 60
}

Device not updating

• Check that the device MAC in config matches exactly (uppercase, with colons)
• Verify the device is pointing to your Byonk server
• Check device WiFi connectivity

Real-World Example: Transit Departures

Here’s what a more complex screen looks like - the built-in transit departure display:

This screen demonstrates:

• Fetching live data from an API
• Processing JSON responses
• Dynamic refresh rates (updates after each bus departs)
• Styled table layout with alternating rows
• Color-coded line badges

Check out screens/transit.lua and screens/transit.svg in the Byonk source for the complete implementation.

What’s Next?

Now that you have a basic screen working, learn more about:

• Lua Scripting - Fetch data from APIs
• SVG Templates - Create complex layouts

Lua Scripting

Lua scripts are the data engine of Byonk screens. They fetch, process, and transform data before it’s rendered by the template. This guide covers all the APIs available to your scripts.

Script Structure

Every Lua script must return a table with data and refresh_rate:

-- Optional: Use params from config.yaml
local my_param = params.some_key or "default"

-- Your logic here
local result = do_something()

-- Required: Return data for template
return {
  data = {
    -- Passed to SVG template
  },
  refresh_rate = 300  -- Seconds until next refresh
}

Parameters

Device-specific parameters are available via the global params table:

# config.yaml
devices:
  "94:A9:90:8C:6D:18":
    screen: weather
    params:
      city: "Zurich"
      units: "metric"

-- In your script
local city = params.city        -- "Zurich"
local units = params.units      -- "metric"
local missing = params.other    -- nil (not defined)

-- Always provide defaults
local limit = params.limit or 10

HTTP Requests

http_get(url)

Fetches a URL and returns the response body as a string.

local response = http_get("https://api.example.com/data")

Error handling:

local ok, response = pcall(function()
  return http_get("https://api.example.com/data")
end)

if not ok then
  log_error("Request failed: " .. tostring(response))
  return {
    data = { error = "Failed to fetch data" },
    refresh_rate = 60
  }
end

URL encoding:

local city = "Zürich, Schweiz"
local encoded = city:gsub(" ", "%%20"):gsub(",", "%%2C")
local url = "https://api.example.com/city?name=" .. encoded

JSON

json_decode(string)

Parses a JSON string into a Lua table.

local response = http_get("https://api.example.com/data")
local data = json_decode(response)

-- Access fields
local name = data.name
local items = data.items
local first = data.items[1]  -- Lua arrays are 1-indexed!

json_encode(table)

Converts a Lua table to a JSON string.

local data = { name = "test", values = {1, 2, 3} }
local json_str = json_encode(data)
-- '{"name":"test","values":[1,2,3]}'

HTML Parsing

For scraping web pages, Byonk provides CSS selector-based HTML parsing.

html_parse(html)

Parses an HTML string and returns a document object.

local html = http_get("https://example.com")
local doc = html_parse(html)

doc:select(selector)

Queries elements using CSS selectors. Returns an elements collection.

local links = doc:select("a.nav-link")
local rows = doc:select("table.data tr")
local header = doc:select("h1")

doc:select_one(selector)

Returns only the first matching element (or nil).

local title = doc:select_one("title")
if title then
  log_info("Page title: " .. title:text())
end

elements:each(fn)

Iterates over matched elements.

local items = {}
doc:select("ul.list li"):each(function(el)
  table.insert(items, {
    text = el:text(),
    link = el:attr("href")
  })
end)

element:text()

Gets the inner text content.

local heading = doc:select_one("h1")
local text = heading:text()  -- "Welcome to Example"

element:attr(name)

Gets an attribute value.

local link = doc:select_one("a")
local href = link:attr("href")   -- "https://..."
local class = link:attr("class") -- "nav-link"

element:html()

Gets the inner HTML.

local div = doc:select_one("div.content")
local inner_html = div:html()

Example: Scraping a Table

local html = http_get("https://example.com/data")
local doc = html_parse(html)

local rows = {}
doc:select("table tbody tr"):each(function(row)
  local cells = {}
  row:select("td"):each(function(cell)
    table.insert(cells, cell:text())
  end)

  if #cells >= 2 then
    table.insert(rows, {
      name = cells[1],
      value = cells[2]
    })
  end
end)

return {
  data = { rows = rows },
  refresh_rate = 900
}

Time Functions

time_now()

Returns the current Unix timestamp (seconds since 1970).

local now = time_now()  -- e.g., 1703672400

time_format(timestamp, format)

Formats a timestamp into a string using strftime patterns.

local now = time_now()

time_format(now, "%H:%M")        -- "14:32"
time_format(now, "%H:%M:%S")     -- "14:32:05"
time_format(now, "%Y-%m-%d")     -- "2024-12-27"
time_format(now, "%A")           -- "Friday"
time_format(now, "%B %d, %Y")    -- "December 27, 2024"

Common format codes:

time_parse(string, format)

Parses a date string into a Unix timestamp.

local ts = time_parse("2024-12-27 14:30", "%Y-%m-%d %H:%M")

Logging

Write messages to the Byonk server logs.

log_info("Processing request for station: " .. station)
log_warn("API returned empty response")
log_error("Failed to parse JSON: " .. err)

Logs appear in the server output:

INFO script=true: Processing request for station: Olten
WARN script=true: API returned empty response
ERROR script=true: Failed to parse JSON: unexpected token

Complete Example: Transit API

Here’s a real-world example fetching transit data:

-- transit.lua - Fetch public transport departures

local station = params.station or "Olten"
local limit = params.limit or 8

log_info("Fetching departures for: " .. station)

-- URL encode the station name
local encoded = station:gsub(" ", "%%20"):gsub(",", "%%2C")
local url = "https://transport.opendata.ch/v1/stationboard"
      .. "?station=" .. encoded
      .. "&limit=" .. limit

-- Fetch with error handling
local ok, response = pcall(function()
  return http_get(url)
end)

if not ok then
  log_error("API request failed: " .. tostring(response))
  return {
    data = {
      station = station,
      error = "Failed to fetch departures",
      departures = {}
    },
    refresh_rate = 60
  }
end

-- Parse JSON
local json = json_decode(response)

-- Transform data for template
local departures = {}
local now = time_now()

for i, dep in ipairs(json.stationboard or {}) do
  local departure_time = dep.stop and dep.stop.departure or ""
  local hour, min = departure_time:match("T(%d+):(%d+)")

  table.insert(departures, {
    time = hour and (hour .. ":" .. min) or "??:??",
    line = (dep.category or "") .. (dep.number or ""),
    destination = dep.to or "Unknown",
    delay = dep.stop and dep.stop.delay or 0
  })
end

-- Calculate smart refresh rate
local refresh_rate = 300
if #departures > 0 and json.stationboard[1].stop then
  local first_dep = json.stationboard[1].stop.departureTimestamp
  if first_dep then
    local seconds_until = first_dep - now
    refresh_rate = math.max(30, math.min(seconds_until + 30, 900))
  end
end

log_info("Found " .. #departures .. " departures, refresh in " .. refresh_rate .. "s")

return {
  data = {
    station = json.station and json.station.name or station,
    departures = departures,
    updated_at = time_format(now, "%H:%M")
  },
  refresh_rate = refresh_rate
}

Tips & Best Practices

Always Handle Errors

local ok, result = pcall(function()
  return http_get(url)
end)

if not ok then
  return { data = { error = "..." }, refresh_rate = 60 }
end

Provide Default Values

local limit = params.limit or 10
local show_delays = params.show_delays or true

Log for Debugging

log_info("Params: " .. json_encode(params))
log_info("Fetched " .. #items .. " items")

Keep It Simple

Scripts run on every request. Avoid:

• Complex computations
• Multiple HTTP requests when one will do
• Parsing more data than needed

Use Smart Refresh Rates

Don’t refresh more often than necessary:

-- Real-time data: 30-60 seconds
-- Regular updates: 300-900 seconds
-- Static content: 3600+ seconds

Next Steps

• SVG Templates - Design the visual layout
• Advanced Topics - Error handling, caching strategies

SVG Templates

SVG templates define the visual layout of your screens. They use Tera templating syntax to insert data from your Lua scripts.

Template Basics

A Byonk SVG template is a standard SVG file with Tera expressions:

<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 800 480" width="800" height="480">
  <rect width="800" height="480" fill="white"/>

  <text x="400" y="240" text-anchor="middle" font-size="24">
    {{ message }}
  </text>
</svg>

Key points:

• Set viewBox to 0 0 800 480 for TRMNL OG (or 0 0 1872 1404 for TRMNL X)
• Always include width and height attributes
• Use {{ variable }} to insert values from Lua

Display Dimensions

Byonk automatically scales your SVG to fit the display, but matching the aspect ratio gives the best results.

Variables

Template Namespaces

Variables in templates are organized into three namespaces:

Device Variables

These are automatically available under device.*:

<!-- Display battery and signal in header -->
<text class="status" x="780" y="25" text-anchor="end">
  {% if device.battery_voltage %}{{ device.battery_voltage | round(precision=2) }}V{% endif %}
  {% if device.rssi %} · {{ device.rssi }}dBm{% endif %}
</text>

<!-- Responsive layout based on device dimensions -->
{% if device.width == 1872 %}
  <!-- TRMNL X layout (1872x1404) -->
{% else %}
  <!-- TRMNL OG layout (800x480) -->
{% endif %}

Note: Some device variables may be nil if the device doesn’t report them. Always use {% if device.variable %} to check before using.

Basic Interpolation

<text>{{ data.title }}</text>
<text>{{ data.user.name }}</text>
<text>{{ data.items[0].label }}</text>

Filters

Apply filters to modify values:

<!-- Truncate long text -->
<text>{{ data.description | truncate(length=50) }}</text>

<!-- Format timestamp (uses UTC) -->
<text>{{ data.updated_at | format_time(format="%H:%M") }}</text>

<!-- Get length -->
<text>{{ data.items | length }} items</text>

Tip: The format_time template filter uses UTC timezone. For local time formatting, use time_format() in your Lua script and pass the pre-formatted string to the template.

Default Values

<text>{{ data.title | default(value="Untitled") }}</text>

Control Flow

Conditionals

{% if data.error %}
  <text fill="red">Error: {{ data.error }}</text>
{% else %}
  <text>All systems operational</text>
{% endif %}

Comparisons

{% if data.count > 0 %}
  <text>{{ data.count }} items</text>
{% elif data.count == 0 %}
  <text>No items</text>
{% endif %}

{% if data.status == "active" %}
  <circle fill="green" r="10"/>
{% endif %}

Boolean Checks

{% if data.is_online %}
  <text fill="green">Online</text>
{% endif %}

{% if not data.items %}
  <text>No data available</text>
{% endif %}

Loops

Basic Loop

{% for item in data.items %}
  <text y="{{ 100 + loop.index0 * 30 }}">{{ item.name }}</text>
{% endfor %}

Loop Variables

Positioning with Loops

{% for dep in data.departures %}
  <!-- Calculate Y position based on index -->
  <text y="{{ 80 + loop.index0 * 40 }}">
    {{ dep.time }} - {{ dep.destination }}
  </text>
{% endfor %}

Conditional Styling in Loops

{% for item in data.items %}
  <!-- Alternating row backgrounds -->
  {% if loop.index0 is odd %}
    <rect y="{{ 100 + loop.index0 * 40 }}" width="800" height="40" fill="#f5f5f5"/>
  {% endif %}

  <text y="{{ 125 + loop.index0 * 40 }}">{{ item.name }}</text>
{% endfor %}

Empty State

{% if data.items | length > 0 %}
  {% for item in data.items %}
    <text>{{ item.name }}</text>
  {% endfor %}
{% else %}
  <text fill="#999">No items found</text>
{% endif %}

Styling

Inline Styles

<text x="20" y="40"
      font-family="sans-serif"
      font-size="24"
      font-weight="bold"
      fill="black">
  {{ data.title }}
</text>

CSS in Style Block

<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 800 480">
  <style>
    .title { font-family: sans-serif; font-size: 32px; font-weight: bold; }
    .subtitle { font-family: sans-serif; font-size: 18px; fill: #666; }
    .highlight { fill: #333; font-weight: bold; }
  </style>

  <text class="title" x="20" y="40">{{ data.title }}</text>
  <text class="subtitle" x="20" y="70">{{ data.subtitle }}</text>
</svg>

Variable Fonts

Byonk supports variable fonts via CSS font-variation-settings:

<style>
  .light { font-family: Outfit; font-variation-settings: "wght" 300; }
  .regular { font-family: Outfit; font-variation-settings: "wght" 400; }
  .bold { font-family: Outfit; font-variation-settings: "wght" 700; }
</style>

Note: Place custom font files (e.g., Outfit-Variable.ttf) in the fonts/ directory.

Colors and Grayscale

E-ink displays only show 4 gray levels. Design with this in mind:

Recommended Colors

<style>
  .black { fill: rgb(0, 0, 0); }       /* Level 0 - Black */
  .dark { fill: rgb(85, 85, 85); }     /* Level 1 - Dark gray */
  .light { fill: rgb(170, 170, 170); } /* Level 2 - Light gray */
  .white { fill: rgb(255, 255, 255); } /* Level 3 - White */
</style>

Testing Grayscale

The included graytest.svg demonstrates all 4 levels:

<rect x="0" y="0" width="200" height="480" fill="rgb(0,0,0)"/>
<rect x="200" y="0" width="200" height="480" fill="rgb(85,85,85)"/>
<rect x="400" y="0" width="200" height="480" fill="rgb(170,170,170)"/>
<rect x="600" y="0" width="200" height="480" fill="rgb(255,255,255)"/>

Rendered output:

Avoid

• Gradients - Convert to dithered patterns (may look noisy)
• Subtle color differences - May become indistinguishable
• Many gray levels - Only 4 will render

Layout Patterns

Header + Content

<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 800 480">
  <!-- Header bar -->
  <rect width="800" height="70" fill="black"/>
  <text x="30" y="48" fill="white" font-size="28">{{ data.title }}</text>
  <text x="770" y="48" fill="#aaa" font-size="14" text-anchor="end">{{ data.time }}</text>

  <!-- Content area -->
  <g transform="translate(0, 70)">
    <!-- Your content here, Y coordinates start at 0 -->
  </g>
</svg>

Grid Layout

{% for item in data.items %}
  {% set col = loop.index0 % 3 %}
  {% set row = loop.index0 // 3 %}

  <rect x="{{ col * 266 }}" y="{{ 80 + row * 100 }}"
        width="260" height="90" fill="#f0f0f0" rx="5"/>
  <text x="{{ col * 266 + 130 }}" y="{{ 130 + row * 100 }}"
        text-anchor="middle">{{ item.name }}</text>
{% endfor %}

Two Columns

<!-- Left column -->
<text x="30" y="100">Left content</text>

<!-- Divider -->
<line x1="400" y1="80" x2="400" y2="450" stroke="#ccc"/>

<!-- Right column -->
<text x="430" y="100">Right content</text>

Dynamic Styling

Conditional Colors

{% for item in data.items %}
  <text fill="{% if item.is_urgent %}red{% else %}black{% endif %}">
    {{ item.name }}
  </text>
{% endfor %}

Dynamic Classes

<text class="{% if data.count > 100 %}highlight{% else %}normal{% endif %}">
  {{ data.count }}
</text>

Status Indicators

{% if data.status == "online" %}
  <circle cx="20" cy="20" r="8" fill="green"/>
{% elif data.status == "warning" %}
  <circle cx="20" cy="20" r="8" fill="orange"/>
{% else %}
  <circle cx="20" cy="20" r="8" fill="red"/>
{% endif %}

Common Patterns

Truncating Long Text

<text>
  {% if data.title | length > 30 %}
    {{ data.title | truncate(length=30) }}
  {% else %}
    {{ data.title }}
  {% endif %}
</text>

Formatted Numbers

Use Lua to format numbers before passing to template:

-- In Lua script
return {
  data = {
    temperature = string.format("%.1f°C", temp),
    price = string.format("$%.2f", amount)
  }
}

Time-Based Styling

-- In Lua script
local hour = tonumber(time_format(time_now(), "%H"))
return {
  data = {
    is_night = hour < 6 or hour > 20
  }
}

<rect width="800" height="480" fill="{% if is_night %}#333{% else %}white{% endif %}"/>

Debugging Templates

Show Raw Data

<!-- Temporarily add this to see all data -->
<text x="10" y="460" font-size="10" fill="#999">
  Debug: {{ data.items | length }} items
</text>

Check for Missing Data

{% if not data.title %}
  <text fill="red">ERROR: title is missing!</text>
{% endif %}

Template Errors

If your template has a syntax error, Byonk will display an error screen with the message. Check the server logs for details.

Embedding Images

Byonk supports embedding images in your SVG templates. You can include PNG, JPEG, GIF, WebP, and SVG files.

Asset Directory Structure

Place your screen assets in a subdirectory matching your screen name:

screens/
├── hello.lua         # Script at top level
├── hello.svg         # Template at top level
└── hello/            # Assets for "hello" screen
    ├── logo.png
    ├── icon.svg
    └── background.jpg

Method 1: Direct in SVG (Automatic Resolution)

Simply reference images by filename in your SVG template. Byonk automatically resolves relative paths to the screen’s asset directory and embeds them as data URIs:

<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 800 480">
  <!-- This automatically loads screens/hello/logo.png -->
  <image x="10" y="10" width="64" height="64" href="logo.png"/>

  <text x="100" y="50">{{ data.greeting }}</text>
</svg>

Supported image formats:

• PNG (.png)
• JPEG (.jpg, .jpeg)
• GIF (.gif)
• WebP (.webp)
• SVG (.svg)

Notes:

• Paths are relative to the screen’s asset directory
• URLs starting with data:, http://, or https:// are left unchanged
• Missing images log a warning but don’t break rendering

Method 2: Via Lua (For Dynamic Images)

For more control, use read_asset() and base64_encode() in your Lua script:

screens/hello.lua:

local icon = read_asset("icon.png")

return {
    data = {
        greeting = "Hello World!",
    },
    refresh_rate = 3600
}

screens/hello.svg:

<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 800 480">
  <image x="10" y="10" width="64" height="64" href="{{ data.icon_src }}"/>
  <text x="100" y="50">{{ data.greeting }}</text>
</svg>

This method is useful when you need to:

• Conditionally include images
• Fetch images from external URLs
• Process or transform image data

Background Images

To use a full-screen background image:

<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 800 480" width="800" height="480">
  <!-- Background image -->
  <image x="0" y="0" width="800" height="480" href="background.png" preserveAspectRatio="xMidYMid slice"/>

  <!-- Content on top -->
  <text x="400" y="240" text-anchor="middle" fill="white" font-size="32">
    {{ data.title }}
  </text>
</svg>

Tips for background images:

• Use preserveAspectRatio="xMidYMid slice" to cover the entire area
• Consider e-ink limitations: high-contrast images work best
• Keep file sizes reasonable for fast rendering

Next Steps

• Advanced Topics - HTML scraping, error handling
• API Reference - Complete Lua function reference

Advanced Topics

This guide covers advanced techniques for building robust Byonk screens.

Error Handling

Graceful HTTP Failures

Always wrap HTTP requests in pcall:

local function fetch_data(url)
  local ok, response = pcall(function()
    return http_get(url)
  end)

  if not ok then
    log_error("HTTP request failed: " .. tostring(response))
    return nil, response
  end

  return response, nil
end

-- Usage
local data, err = fetch_data("https://api.example.com/data")
if err then
  return {
    data = { error = "Could not fetch data" },
    refresh_rate = 60  -- Retry in 1 minute
  }
end

JSON Parsing Errors

local function safe_json_decode(str)
  local ok, result = pcall(function()
    return json_decode(str)
  end)

  if not ok then
    log_error("JSON parse error: " .. tostring(result))
    return nil
  end

  return result
end

Template Error Display

When errors occur, display them helpfully:

return {
  data = {
    has_error = true,
    error_message = "API returned invalid response",
    error_details = "Expected JSON, got HTML",
    retry_in = 60
  },
  refresh_rate = 60
}

{% if has_error %}
  <rect x="20" y="20" width="760" height="440" fill="white" stroke="red" stroke-width="4" rx="10"/>
  <text x="400" y="200" text-anchor="middle" font-size="24" fill="red">{{ error_message }}</text>
  <text x="400" y="240" text-anchor="middle" font-size="16" fill="#666">{{ error_details }}</text>
  <text x="400" y="300" text-anchor="middle" font-size="14" fill="#999">Retrying in {{ retry_in }} seconds...</text>
{% else %}
  <!-- Normal content -->
{% endif %}

HTML Scraping Techniques

Handling Missing Elements

local function safe_text(element)
  if element then
    return element:text()
  end
  return ""
end

local title = safe_text(doc:select_one("h1"))

Complex Table Parsing

local function parse_table(doc, selector)
  local rows = {}

  doc:select(selector .. " tr"):each(function(row)
    local cells = {}
    row:select("td, th"):each(function(cell)
      table.insert(cells, cell:text():match("^%s*(.-)%s*$"))  -- Trim whitespace
    end)

    if #cells > 0 then
      table.insert(rows, cells)
    end
  end)

  return rows
end

local data = parse_table(doc, "table.schedule")
-- Returns: { {"9:00", "Meeting"}, {"10:00", "Call"}, ... }

Following Links

local function get_detail_page(doc, selector)
  local link = doc:select_one(selector)
  if not link then return nil end

  local href = link:attr("href")
  if not href then return nil end

  -- Handle relative URLs
  if href:sub(1, 1) == "/" then
    href = "https://example.com" .. href
  end

  return http_get(href)
end

Handling Pagination

local all_items = {}
local page = 1

while true do
  local url = "https://example.com/list?page=" .. page
  local html = http_get(url)
  local doc = html_parse(html)

  local items_found = 0
  doc:select(".item"):each(function(el)
    table.insert(all_items, el:text())
    items_found = items_found + 1
  end)

  -- Stop if no items or we have enough
  if items_found == 0 or #all_items >= 50 then
    break
  end

  page = page + 1

  -- Safety limit
  if page > 10 then break end
end

Dynamic Refresh Rates

Time-Based Refresh

local now = time_now()
local hour = tonumber(time_format(now, "%H"))

local refresh_rate
if hour >= 6 and hour < 22 then
  -- Daytime: refresh frequently
  refresh_rate = 300
else
  -- Night: refresh less often
  refresh_rate = 3600
end

Event-Based Refresh

-- Refresh when the next event starts
local next_event_time = events[1].timestamp
local seconds_until = next_event_time - time_now()

-- Refresh 30 seconds after event starts (to show updated state)
local refresh_rate = math.max(30, seconds_until + 30)

-- Cap at reasonable maximum
refresh_rate = math.min(refresh_rate, 3600)

Adaptive Refresh

-- Refresh more often if data is stale
local last_update = data.updated_timestamp
local age = time_now() - last_update

if age > 600 then
  -- Data is stale, refresh soon
  refresh_rate = 60
else
  -- Data is fresh, normal refresh
  refresh_rate = 300
end

Data Transformation

Sorting

-- Sort by time
table.sort(items, function(a, b)
  return a.timestamp < b.timestamp
end)

-- Sort alphabetically
table.sort(items, function(a, b)
  return a.name < b.name
end)

Filtering

local active = {}
for _, item in ipairs(items) do
  if item.status == "active" then
    table.insert(active, item)
  end
end

Limiting

local limit = params.limit or 10
local limited = {}
for i = 1, math.min(#items, limit) do
  table.insert(limited, items[i])
end

Grouping

local by_category = {}
for _, item in ipairs(items) do
  local cat = item.category or "Other"
  if not by_category[cat] then
    by_category[cat] = {}
  end
  table.insert(by_category[cat], item)
end

Working with Dates

Relative Time

local function relative_time(timestamp)
  local diff = timestamp - time_now()

  if diff < 0 then
    return "past"
  elseif diff < 60 then
    return "now"
  elseif diff < 3600 then
    return math.floor(diff / 60) .. " min"
  elseif diff < 86400 then
    return math.floor(diff / 3600) .. " hr"
  else
    return math.floor(diff / 86400) .. " days"
  end
end

Date Comparison

local today_start = time_parse(time_format(time_now(), "%Y-%m-%d"), "%Y-%m-%d")
local today_end = today_start + 86400

local todays_events = {}
for _, event in ipairs(events) do
  if event.timestamp >= today_start and event.timestamp < today_end then
    table.insert(todays_events, event)
  end
end

Timezone Handling

-- time_format uses local timezone
-- For UTC, parse the offset from API responses

local function parse_iso_date(str)
  -- "2024-12-27T14:30:00+01:00"
  local y, m, d, h, min, s = str:match("(%d+)-(%d+)-(%d+)T(%d+):(%d+):(%d+)")
  if y then
    return time_parse(
      string.format("%s-%s-%s %s:%s:%s", y, m, d, h, min, s),
      "%Y-%m-%d %H:%M:%S"
    )
  end
  return nil
end

Performance Optimization

Minimize HTTP Requests

-- Bad: Multiple requests
local weather = json_decode(http_get("https://api.example.com/weather"))
local news = json_decode(http_get("https://api.example.com/news"))
local stocks = json_decode(http_get("https://api.example.com/stocks"))

-- Better: Combined endpoint if available
local dashboard = json_decode(http_get("https://api.example.com/dashboard"))

Early Exit

-- Check for errors early
if not params.api_key then
  return {
    data = { error = "Missing API key" },
    refresh_rate = 3600
  }
end

Limit Data Processing

-- Only process what you need
local limit = params.limit or 10
for i, item in ipairs(json.items) do
  if i > limit then break end
  -- Process item
end

Testing Strategies

Test with Swagger UI

1. Open http://localhost:3000/swagger-ui
2. Use /api/display with a test MAC address
3. Copy the image URL and open in browser
4. Iterate on your script and template

Log Intermediate Values

log_info("Params: " .. json_encode(params))
log_info("Fetched " .. #items .. " items")
log_info("First item: " .. json_encode(items[1]))

Create Test Screens

# config.yaml
devices:
  "TE:ST:00:00:00:01":
    screen: myscreen
    params:
      test_mode: true
      mock_data: true

if params.test_mode then
  -- Use mock data for testing
  return {
    data = {
      items = {
        { name = "Test Item 1" },
        { name = "Test Item 2" }
      }
    },
    refresh_rate = 30
  }
end

-- Normal data fetching

Real-World Example: Room Booking

This example combines many advanced techniques:

-- floerli.lua - Room booking display

local room_name = params.room or "Rosa"
local base_url = params.url or "https://floerli-olten.ch"

log_info("Fetching bookings for room: " .. room_name)

-- Fetch and parse
local ok, html = pcall(function()
  return http_get(base_url .. "/index.cgi?rm=calendar")
end)

if not ok then
  log_error("Failed to fetch calendar: " .. tostring(html))
  return {
    data = {
      room = room_name,
      error = "Could not load calendar",
      bookings = {}
    },
    refresh_rate = 60
  }
end

local doc = html_parse(html)

-- Find room column index
local room_columns = {
  Flora = 1, Salon = 2, ["Küche"] = 3, Bernsteinzimmer = 4,
  Rosa = 5, Clara = 6, Cosy = 7, Sofia = 8
}
local col = room_columns[room_name] or 5

-- Parse table
local bookings = {}
local now = time_now()
local current_hour = tonumber(time_format(now, "%H"))

doc:select("table.calendar tr"):each(function(row)
  local time_cell = row:select_one("td:first-child")
  local room_cell = row:select_one("td:nth-child(" .. (col + 1) .. ")")

  if time_cell and room_cell then
    local time_str = time_cell:text()
    local hour = tonumber(time_str:match("^(%d+)"))

    if hour and hour >= current_hour then
      local booking_text = room_cell:text():match("^%s*(.-)%s*$")
      local is_free = (booking_text == "" or booking_text == "frei")

      table.insert(bookings, {
        time = time_str,
        title = is_free and nil or booking_text,
        is_free = is_free
      })
    end
  end
end)

-- Calculate refresh: at top of next hour
local minutes_until_next_hour = 60 - tonumber(time_format(now, "%M"))
local refresh_rate = math.max(60, minutes_until_next_hour * 60)

return {
  data = {
    room = room_name,
    bookings = bookings,
    current_booking = bookings[1],
    upcoming = { table.unpack(bookings, 2, 6) },
    updated_at = time_format(now, "%H:%M")
  },
  refresh_rate = refresh_rate
}

Next Steps

• HTTP API Reference - Full endpoint documentation
• Lua API Reference - Complete function reference

HTTP API Reference

Bring Your Own Server API for TRMNL e-ink devices

Version: 0.1.0

Overview

Byonk provides a REST API for TRMNL device communication. The API handles device registration, content delivery, and logging.

Display

GET /api/display

Get display content for a device

Returns JSON with an image_url that the device should fetch separately. The firmware expects status=0 for success (not HTTP 200).

Parameters

Responses

200: Display content available

{
  "filename": "string",
  "firmware_url": null,
  "image_url": null,
  "refresh_rate": 0,
  "reset_firmware": true,
  "special_function": null,
  "status": 0,
  "temperature_profile": null,
  "update_firmware": true
}

400: Missing required header

404: Device not found

GET /api/image/{hash}.png

Get rendered PNG image by content hash

Returns the actual PNG image data rendered from SVG with dithering applied. The content hash is provided in the /api/display response and ensures clients can detect when content has changed.

Parameters

Responses

200: PNG image

404: Content not found (hash expired or invalid)

500: Rendering error

Logging

POST /api/log

Submit device logs

Devices send diagnostic logs when they encounter errors or issues.

Parameters

Request Body

{
  "logs": [null]
}

Responses

200: Logs received successfully

{
  "message": "string",
  "status": 0
}

Device

GET /api/setup

Register a new device or retrieve existing registration

The device sends its MAC address and receives an API key for future requests.

Parameters

Responses

200: Device registered successfully

{
  "api_key": null,
  "friendly_id": null,
  "image_url": null,
  "message": null,
  "status": 0
}

400: Missing required header

Lua API Reference

This page documents all functions available to Lua scripts in Byonk.

Global Variables

params

A table containing device-specific parameters from config.yaml.

local station = params.station  -- From config.yaml
local limit = params.limit or 10  -- With default

Type: table

device

A table containing device information (when available).

-- Check battery level
if device.battery_voltage and device.battery_voltage < 3.3 then
  log_warn("Low battery: " .. device.battery_voltage .. "V")
end

-- Check signal strength
if device.rssi and device.rssi < -80 then
  log_warn("Weak WiFi signal: " .. device.rssi .. " dBm")
end

-- Responsive layout based on device type
if device.width == 1872 then
  -- TRMNL X layout
else
  -- TRMNL OG layout
end

Fields:

Type: table

Note: Device fields may be nil if the device doesn’t report them. Always check before using.

HTTP Functions

http_get(url)

Performs an HTTP GET request and returns the response body.

local response = http_get("https://api.example.com/data")

Parameters:

Returns: string - The response body

Throws: Error if the request fails

Example with error handling:

local ok, response = pcall(function()
  return http_get("https://api.example.com/data")
end)

if not ok then
  log_error("Request failed: " .. tostring(response))
end

JSON Functions

json_decode(str)

Parses a JSON string into a Lua table.

local data = json_decode('{"name": "Alice", "age": 30}')
print(data.name)  -- "Alice"

Parameters:

Returns: table - The parsed JSON as a Lua table

Notes:

• JSON arrays become 1-indexed Lua tables
• JSON null becomes Lua nil

json_encode(table)

Converts a Lua table to a JSON string.

local json = json_encode({name = "Bob", items = {1, 2, 3}})
-- '{"name":"Bob","items":[1,2,3]}'

Parameters:

Returns: string - JSON representation

Notes:

• Tables with sequential integer keys become arrays
• Tables with string keys become objects

HTML Parsing Functions

html_parse(html)

Parses an HTML string and returns a document object.

local doc = html_parse("<html><body><h1>Hello</h1></body></html>")

Parameters:

Returns: Document - Parsed document object

Document Methods

doc:select(selector)

Queries elements using a CSS selector.

local links = doc:select("a.nav-link")
local items = doc:select("ul > li")

Parameters:

Returns: Elements - Collection of matching elements

Supported selectors:

• Tag: div, a, span
• Class: .classname
• ID: #idname
• Attribute: [href], [data-id="123"]
• Combinators: div > p, ul li, h1 + p
• Pseudo-classes: :first-child, :nth-child(2)

doc:select_one(selector)

Returns only the first matching element.

local title = doc:select_one("h1")
if title then
  print(title:text())
end

Parameters:

Returns: Element or nil - First matching element

Elements Methods

elements:each(fn)

Iterates over all elements in the collection.

doc:select("li"):each(function(el)
  print(el:text())
end)

Parameters:

Element Methods

element:text()

Gets the inner text content.

local heading = doc:select_one("h1")
local text = heading:text()  -- "Welcome"

Returns: string - Text content

element:attr(name)

Gets an attribute value.

local link = doc:select_one("a")
local href = link:attr("href")  -- "https://..."
local class = link:attr("class")  -- "nav-link" or nil

Parameters:

Returns: string or nil - Attribute value

element:html()

Gets the inner HTML.

local div = doc:select_one("div.content")
local inner = div:html()  -- "<p>Paragraph</p><p>Another</p>"

Returns: string - Inner HTML

element:select(selector)

Queries descendants of this element.

local table = doc:select_one("table.data")
local rows = table:select("tr")

Parameters:

Returns: Elements - Matching descendants

element:select_one(selector)

Returns first matching descendant.

local row = doc:select_one("tr")
local first_cell = row:select_one("td")

Parameters:

Returns: Element or nil

Time Functions

time_now()

Returns the current Unix timestamp.

local now = time_now()  -- e.g., 1703672400

Returns: number - Unix timestamp (seconds since 1970)

time_format(timestamp, format)

Formats a timestamp into a string using the server’s local timezone.

local now = time_now()
time_format(now, "%H:%M")      -- "14:32"
time_format(now, "%Y-%m-%d")   -- "2024-12-27"
time_format(now, "%A, %B %d")  -- "Friday, December 27"

Parameters:

Returns: string - Formatted date/time

Format codes:

time_parse(str, format)

Parses a date string into a Unix timestamp.

local ts = time_parse("2024-12-27 14:30", "%Y-%m-%d %H:%M")

Parameters:

Returns: number - Unix timestamp

Note: Uses local timezone for interpretation.

Asset Functions

read_asset(path)

Reads a file from the current screen’s asset directory.

-- From hello.lua, reads screens/hello/logo.png
local logo_bytes = read_asset("logo.png")

Parameters:

Returns: string - Binary file contents

Throws: Error if the file cannot be read

Asset directory convention:

screens/
├── hello.lua         # Script at top level
├── hello.svg         # Template at top level
└── hello/            # Assets for "hello" screen
    ├── logo.png
    └── icon.svg

When read_asset("logo.png") is called from hello.lua, it reads screens/hello/logo.png.

Example: Embedding an image in data:

local logo = read_asset("logo.png")
local logo_b64 = base64_encode(logo)

return {
    data = {
    },
    refresh_rate = 3600
}

base64_encode(data)

Encodes binary data (string) to a base64 string.

local encoded = base64_encode(raw_bytes)

Parameters:

Returns: string - Base64-encoded string

Example: Creating a data URI:

local image_data = read_asset("icon.png")

Logging Functions

log_info(message)

Logs an informational message.

log_info("Processing request for: " .. station)

Parameters:

Server output:

INFO script=true: Processing request for: Olten

log_warn(message)

Logs a warning message.

log_warn("API response was empty")

Parameters:

log_error(message)

Logs an error message.

log_error("Failed to parse response: " .. err)

Parameters:

Script Return Value

Every script must return a table with this structure:

return {
  data = {
    -- Any data structure
    -- Available in template as data.*
    title = "My Title",
    items = { ... }
  },
  refresh_rate = 300,  -- Seconds until next refresh
  skip_update = false  -- Optional: skip rendering, just check back later
}

data

The data table can contain any Lua values:

• Strings, numbers, booleans
• Nested tables (become objects)
• Arrays (1-indexed tables with sequential keys)

In templates, access this data with the data. prefix:

<text>{{ data.title }}</text>
{% for item in data.items %}...{% endfor %}

refresh_rate

Guidelines:

• 30-60: Real-time data (transit, stocks)
• 300-900: Regular updates (weather, calendar)
• 3600+: Static or slow-changing content

If refresh_rate is 0 or omitted, the screen’s default_refresh from config is used.

skip_update

When skip_update is true:

• No new image is rendered
• The device keeps its current display content
• The device will check back after refresh_rate seconds

This is useful when your data source hasn’t changed:

-- Check if data has changed since last update
local cached_hash = get_data_hash()
local current_data = fetch_data()
local new_hash = compute_hash(current_data)

if cached_hash == new_hash then
  -- No changes - tell device to check back in 5 minutes
  return {
    data = {},
    refresh_rate = 300,
    skip_update = true
  }
end

-- Data changed - render new content
return {
  data = current_data,
  refresh_rate = 300,
  skip_update = false  -- or just omit it
}

Note: When skip_update is true, the data table is ignored since no rendering occurs.

Standard Lua Functions

Byonk uses Lua 5.4. Standard library functions available include:

String

• string.format, string.sub, string.find
• string.match, string.gmatch, string.gsub
• string.upper, string.lower, string.len

Table

• table.insert, table.remove
• table.sort, table.concat
• ipairs, pairs

Math

• math.floor, math.ceil, math.abs
• math.min, math.max
• math.random

Other

• tonumber, tostring, type
• pcall (for error handling)

Not available: File I/O, OS functions, network (except http_get)
